EX-IT-400LED

Description

Explosionproof light fitting with LED modules. Designed to work in the zone 21 & 2.22 of the explosion hazard of gases, vapors and mists of flammable liquids with air, as well as of flammable dusts and fibers. The housing is made of aluminum and the diffuser is made of polycarbonate or tempered glass.Optional version with autonomous A3, compatible with central battery ZB, or power source or DALI-2 control system DA

Datasheet

Request A Quote Ask About The Product

Types Comparison

Please see datasheet for complete table with additional information.

Narrow Beam Optics- NB

Type	Luminous Flux (lm)	Power Consumption (W)	Efficiency (lm/W)	Max. Temp. / Temp. Class
EXL400LED-0300-E1-2	1462	11	133	+45°C / T6 or +60°C / T5
EXL400LED-0300-E2-1	2500	16,9	148	+45°C / T6 or +60°C / T5
EXL400LED-0600-E2-2	2942	22,1	133	+45°C / T6 or +60°C / T5
EXL400LED-0600-E2-3	3379	25,3	134	+45°C / T6 or +60°C / T5
EXL400LED-0600-E4-1	5055	32	158	+45°C / T6 or +60°C / T5
EXL400LED-0600-E4-2	5904	40,9	144	+45°C / T6 or +60°C / T5
EXL400LED-1200-E4-2	5609	40,9	137	+45°C / T6 or +60°C / T5
EXL400LED-1200-E4-3	6803	47,3	144	+45°C / T6 or +60°C / T5
EXL400LED-1200-E8-1	10034	62,4	161	+45°C / T6 or +60°C / T5
EXL400LED-1200-E8-2	11732	79,7	147	+45°C / T6 or +60°C / T5
EXL400LED-1200-E8-3	13487	91,3	148	+45°C / T6 or +60°C / T5
EXL400LED-1500-E5-2	7592	50,7	150	+45°C / T6 or +60°C / T5
EXL400LED-1500-E5-3	8695	59	147	+45°C / T6 or +60°C / T5
EXL400LED-1500-E10-1	11601	78,6	148	+45°C / T6 or +60°C / T5

Wide Beam Optics- WB

Type	Luminous Flux (lm)	Power Consumption (W)	Efficiency (lm/W)	Max. Temp. / Temp. Class
EXL400LED-0300-E1-2	1413	11	128	+45°C / T6 or +60°C / T5
EXL400LED-0300-E2-1	2416	16,9	143	+45°C / T6 or +60°C / T5
EXL400LED-0600-E2-2	2844	22,1	129	+45°C / T6 or +60°C / T5
EXL400LED-0600-E2-3	3266	25,3	129	+45°C / T6 or +60°C / T5
EXL400LED-0600-E4-1	4973	32	155	+45°C / T6 or +60°C / T5
EXL400LED-0600-E4-2	5808	40,9	142	+45°C / T6 or +60°C / T5
EXL400LED-1200-E4-2	5518	40,9	135	+45°C / T6 or +60°C / T5
EXL400LED-1200-E4-3	6692	47,3	141	+45°C / T6 or +60°C / T5
EXL400LED-1200-E8-1	9872	62,4	158	+45°C / T6 or +60°C / T5
EXL400LED-1200-E8-2	11542	79,7	145	+45°C / T6 or +60°C / T5
EXL400LED-1200-E8-3	13269	91,3	145	+45°C / T6 or +60°C / T5
EXL400LED-1500-E5-2	7352	50,7	145	+45°C / T6 or +60°C / T5
EXL400LED-1500-E5-3	8420	59	143	+45°C / T6 or +60°C / T5
EXL400LED-1500-E10-1	11234	78,6	143	+45°C / T6 or +60°C / T5

Electrical Features

Parameter	Specification
Connection terminals	2,5 mm²
Input voltage (35E)	220–240V 50–60Hz
Input voltage (35E)	220–240V 0Hz
Input voltage (34E)	220–240V 50–60Hz
Input voltage (11E)	24V 0Hz
Light source	Certified LED modules
Power factor	>0,97
Cable inlets	Ø20 (wiring 6–13mm)
Cable inlets (option)	Ø25 (wiring 9–17mm)
Overvoltage protection (35E)	1 kV (L–N), 2 kV (L–PE)
Overvoltage protection (35E option)	4 kV (L–PE)
Overvoltage protection (34E)	1 kV (L–N), 2 kV (L–PE)

Mechanical Features

Parameter	Specification
Housing	Anodized aluminium (ALU)
Diffuser	Tempered glass (GL), polycarbonate (PC), polymethyl methacrylate (PM)
Ingress protection	IP66 / IP67
Protection class	I
Shock resistance	GL: IK09, PC: IK10
Accessibility	Revision cover

Work Parameters

Parameter	Specification
Ambient temperature	-40°C to max. +60°C (check: types comparison)
Lifetime	>70,000 h L80 B10>100,000 h L70 B10

Photometrical Parameters

Parameter	Specification
CRI	>80>90 (optionally)
Colour temperature	4000 K6500 K (optionally)
