Innova
Zone :
Description
Closed and non-dismountable light fitting according to the standard ČSN EN 60598-1 part 4 suitable for indoor and outdoor space (even without shelter), industrial, warehouse and agricultural buildings, sports premises, transport terminals, parking lots and garages, workshops and laboratories without explosion hazard. The structural design of the light fitting (IP69) allows even placement in food-processing industry – HACCP.
Downloads
Types Comparison
Please see datasheet for complete table with additional information.
| Code | Wattage | Luminous Flux | Efficiency (lm/W) |
|---|---|---|---|
| INNOVA 1.4ft PC 2600/840 | 16,1 | 2440 | 152 |
| INNOVA 1.4ft PC 3200/840 | 19,1 | 2910 | 152 |
| INNOVA 1.4ft PC 4400/840 | 26,0 | 4040 | 155 |
| INNOVA 1.4ft PC 6400/840 | 36,1 | 5750 | 159 |
| INNOVA 1.4ft PC 8800/840 | 49,7 | 8170 | 164 |
| INNOVA 1.5ft PC 3250/840 | 19,5 | 3050 | 156 |
| INNOVA 1.5ft PC 4000/840 | 23,3 | 3620 | 156 |
| INNOVA 1.5ft PC 5500/840 | 31,9 | 5020 | 157 |
| INNOVA 1.5ft PC 8000/840 | 44,3 | 7310 | 165 |
| INNOVA 1.5ft PC 11000/840 | 71,1 | 11570 | 163 |
Electrical Features
- Electric equipment: LED modules, fixed output driver or DALI driver
- Wiring: Optional through wiring (up to 5 wires inside light fitting)
- Certification: ESČ, ENEC, CB, HACCP
Mechanical Features
- Housing: Grey polycarbonate
- Diffuser: Translucent polycarbonate
- Ingress protection: IP66/IP69
- Impact strength: IK10
- Mounting: Suitable for suspended, ceiling, wall, and surface mounting via stainless hooks and brackets
Work Parameters
- Ambient Temperatures: up to 50°C
- Lifetime: 50.000h L90 B10
Photometrical Parameters
- CRI: >80 standard
- Colour temperature: 4000K - standard
- CRI >80: 3000K, 5000K, 6500K - on request
- CRI >90: 3000K, 4000K, 5000, 6500K - on request
