Innova ABS
Zone :
Description
Plastic industrial LED light fitting with high chemical resistance, suitable for outdoor use. Features a translucent acrylate diffuser and IP69 rating for dust, humidity, and water resistance up to 80°C. Designed for agricultural and industrial spaces, car washes, and laboratories. Easy installation with external terminal strip.
Downloads
Types Comparison
Please see datasheet for complete table with additional information.
|
Code |
Wattage |
Luminous Flux |
Efficiency (lm/W) |
|---|---|---|---|
| INNOVA 1.4ft ABS 2600/840 | 16,1 | 2420 | 150 |
| INNOVA 1.4ft ABS 3200/840 | 19,1 | 2880 | 151 |
| INNOVA 1.4ft ABS 4400/840 | 26,0 | 4000 | 154 |
| INNOVA 1.4ft ABS 6400/840 | 36,1 | 5690 | 158 |
| INNOVA 1.4ft ABS 8800/840 | 49,7 | 8080 | 163 |
| INNOVA 1.5ft ABS 3250/840 | 19,5 | 6010 | 154 |
| INNOVA 1.5ft ABS 4000/840 | 23,3 | 3580 | 154 |
| INNOVA 1.5ft ABS 5500/840 | 31,9 | 4970 | 156 |
| INNOVA 1.5ft ABS 8000/840 | 44,3 | 7240 | 163 |
Electrical Features
- Electric equipment: LED modules, fixed output driver or DALI driver
- Wiring: Optional through wiring (up to 5 wires inside light fitting)
- Certification: CE, ESČ, ENEC, CB, HACCP, DLG
Mechanical Features
- Housing: Dark grey ABS
- Diffuser: Translucent ABS
- Ingress protection: IP66/IP69
- Impact strength: IK10
- Mounting: Suitable for suspended, ceiling, wall, and surface mounting via stainless hooks and brackets
Work Parameters
- Ambient Temperatures: -25°C to +50°C
- Lifetime: 50.000h L90 B10
Photometrical Parameters
- CRI: >80 standard
- Colour temperature: 4000K - standard
- CRI >80: 3000K, 5000K, 6500K - on request
- CRI >90: 3000K, 4000K, 5000, 6500K - on request
