Perun SLIM Ex
Zone :
Description
Ex II 3G Ex nR IIC T6 Gc
Ex II 3D Ex tc IIIC T70°C Dc
The basic requirements for safety and health protection are secured by the verification of conformity with the standards according to EN 60079-15, EN 60079-0 and EN 60079-31.The light fitting is resistant to deformation, dust, spouting water and have increased chemical resistance. Characteristics of the used tempered glass and its shattering power are controlled by the EN 12150-1 standard. For applications where spontaneous fracture means a higher safety risk.
Downloads
Types Comparison
Please see datasheet for complete table with additional information.
| Code | Wattage | Luminous Flux | Efficiency (lm/W) |
|---|---|---|---|
| Perun SLIM Ex 1.2ft 1600/840 | 11,4 | 1460 | 128 |
| Perun SLIM Ex 1.2ft 2200/840 | 15,4 | 2000 | 130 |
| Perun SLIM Ex 1.4ft 3200/840 | 22,2 | 2900 | 131 |
| Perun SLIM Ex 1.4ft 4400/840 | 30,3 | 4020 | 133 |
| Perun SLIM Ex 1.4ft 6400/840 | 42,1 | 5710 | 136 |
| Perun SLIM Ex 1.4ft 8800/840 | 57,9 | 8110 | 140 |
| Perun SLIM Ex 1.5ft 4000/840 | 27,1 | 3590 | 132 |
| Perun SLIM Ex 1.5ft 5500/840 | 37,2 | 4980 | 134 |
| Perun SLIM Ex 1.5ft 8000/840 | 51,6 | 7260 | 141 |
| Perun SLIM Ex 1.5ft 11000/840 | 71,1 | 9850 | 139 |
Photometrical Parameters
- Colour temperature: 4000K
- CRI: >80
Mechanical Features
- Housing: Stainless sheet, chemically resistant
- Diffuser: Satinated tempered safety glass
- Light fitting protection: IP65
- Mounting: Directly to ceiling or wall with brackets
- Reflector: Steel sheet
Work Parameters
- Ambient Temperatures: -25°C to +45°C (check types comparison)
- Lifetime: 50.000h L90 B10
